L44643LA/L44610 Timken
05939
£37.51
In stock
1
Product Details
Brand:
Timken
Inside Diameter (inch):
1
Outside Diameter (inch):
1.98
Width (inch):
0.58
Commodity Code:
8482200000
Country of Origin:
US
[tab name='Specification']
Part Number: L44643LA/L44610
Brand: Timken
Bearing Type: Single Row Tapered Roller Bearing with DUO-FACE PLUS seal
Dimension(s):
Inside Diameter (d) = 1"
Outside Diameter (D) = 1.98"
Inner Ring Width (B) = 0.58"
Width (T) = 0.588"
Width (T1) = 0.64"
Load Rating(s):
Basic Dynamic Load Rating (kN) = 32.9
Basic Static Load Rating (kN) = 35.6
Alternative Part Number(s):
L44643LA/L44610, 44643LA/44610, L44600LA, 44600LA, L44643LA L44610, 44643LA 44610
[tab name='More Information']
The Single Row Tapered Roller Bearing with DUO-FACE PLUS seal is a specialized and innovative bearing designed to provide superior performance and protection in demanding industrial and automotive applications. This type of bearing combines the benefits of a single row tapered roller bearing with the advanced sealing technology of the DUO-FACE PLUS seal.
The core features of the Single Row Tapered Roller Bearing include a single inner ring (cone), a single outer ring (cup), tapered rollers, and a cage to retain the rollers. The tapered design allows efficient distribution of radial and axial loads, ensuring high load-carrying capacity and excellent durability.
The DUO-FACE PLUS seal is a cutting-edge sealing system integrated into the bearing. It comprises two sealing lips on both sides of the bearing, each serving specific purposes. The primary lip faces inward to provide robust protection against external contaminants like dust, dirt, water, and other harsh elements. It effectively prevents these contaminants from entering the bearing, thus extending its service life and reducing the risk of premature failure.
The secondary lip faces outward and acts as a wiper, ensuring that any internal lubricants, such as grease or oil, remain inside the bearing. This feature not only preserves the lubricant for extended periods but also minimizes friction and wear within the bearing, further enhancing its overall efficiency and longevity.
The Single Row Tapered Roller Bearing with DUO-FACE PLUS seal is particularly well-suited for applications in challenging environments where exposure to contaminants or extreme conditions is common. Industries such as mining, construction, agriculture, and off-road vehicles can greatly benefit from this advanced sealing solution, as it enhances the bearing's resistance to external factors that could otherwise compromise its performance.
In addition to its protective capabilities, the DUO-FACE PLUS seal also contributes to simplified maintenance procedures, as it reduces the need for frequent re-lubrication and servicing. This leads to lower maintenance costs and increased operational efficiency.
Overall, the Single Row Tapered Roller Bearing with DUO-FACE PLUS seal represents a reliable and innovative solution, providing high load-carrying capacity, exceptional protection against contaminants, and extended service life, making it an essential component in various demanding applications.
