NAG4907UU IKO

Part Number: NAG4907UU

Brand: IKO

Bearing Type: Full Complement Roller Bearing

Dimension(s):
Inside Diameter (d) = 35mm
Outside Diameter (D) = 55mm
Width (C) = 20mm
Radius (rs min) = 0.6mm

Other Dimension(s):
(J) = 40mm
(Ew) = 49mm

Load Rating(s):
Basic Dynamic Load Rating (N) = 28700
Basic Static Load Rating (N) = 43800

Speed Limitation(s):
Allowable Rotational Speed (r/min) = 3500

Additional Notes:
1). This bearing is supplied with pre-packed grease.
2). This bearing has an oil groove and oil hole on the outer ring.
3). The allowable rotational speed applies to grease lubrication. Considering that the axial load acts under practical operating conditions, up to 1/10 of this value is recommended for actual use.

More Information:
These bearings are suitable for low-speed rotations or oscillating motions and heavy loads. Similar to the caged type, the structure is advantageous for supporting moment loads. Full complement roller bearings with seals incorporate seals on both sides. Synthetic resin rubber seals are excellent in the prevention of dust penetration and grease leakage, providing an excellent sealing effect.
